Silicon nitride ceramic shafts are a class of high-performance ceramic components primarily made of high-purity silicon nitride.
Silicon nitride ceramic shafts are lighter, more rigid, and have better wear resistance, making them ideal for applications in high-speed rotating equipment, precision bearings, motors, aerospace systems, semiconductor equipment, and industrial automation.
GORGEOUS CERAMICS (GGS) is a custom supplier of precision ceramics, providing customers with optimal, high-quality ceramic shaft solutions.
Silicon nitride ceramic shaft properties
| İsim | Silisyum nitrür | |||
| Yoğunluk | g/cm3 | 3.18-3.40 | ||
| Basınç Dayanımı | MPa | 3000 | ||
| 25°C'de Eğilme Dayanımı | MPa | 760-830 | ||
| Weibull-Modülü m | – | 12-20 | ||
| Kırılma Tokluğu KBEN | MPa m1/2 | 6.2-8 | ||
| Young Modülü | Not ortalaması | 300 | ||
| Sertlik | Not ortalaması | 15 | ||
| Poisson Oranı | – | 0.26 | ||
| Silisyum nitrürün fiziksel özellikleri | ||||
| 20°C'de Isıl İletkenlik | W/mK | 25-28 | ||
| Termal Şok Parametresi R1 | K | 550-690 | ||
| Termal Şok Parametresi R2 | W/m | 15-18 | ||
| CTE1 25°C ➞ 250°C | 10-6/K | 1.9 | ||
| CTE1 25°C ➞ 1000°C | 10-6/K | 3.1 | ||
| Maksimum Sıcaklık (Oksitleyici) 2 | °C | 1400 | ||
| Dielektrik sabiti | °C | 1200 | ||
| Hacim Direnci @ 25°C | ohm-cm | 1014 | ||
Technical specifications, material properties, and performance data are typical values and are for reference only. Actual values may vary depending on manufacturing tolerances, testing conditions, material grades, and application environments.
For critical engineering applications, please contact GORGEOUS CERAMICS (GGS) for detailed material reports, inspection data, and technical support.
Silicon Nitride Ceramic Shaft Applications
High-speed bearings
The most common applications of silicon nitride ceramic shafts are ceramic bearing shafts, hybrid bearing systems, high-speed rotating components, and precision spindle systems. Silicon nitride is chosen because of its low density, lightweight nature, and superior fatigue resistance.
Motors and Drive Systems
Silicon nitride shafts are an ideal choice for motors and drive systems. Common applications include brushless DC motors, servo motors, precision motors, and industrial drive systems.
Automotive Turbocharging Systems
Automotive turbocharging systems represent a significant market for silicon nitride materials. Silicon nitride ceramic shafts effectively reduce inertia, improve response speed, and enhance high-speed operating efficiency. Their main applications include turbocharger rotor shafts, turbocharger bearings, and high-speed rotating components.
Semiconductor Equipment
In semiconductor equipment, silicon nitride ceramic shafts can also be used in wafer processing systems, precision transport mechanisms, vacuum equipment, etc.
Why choose GORGEOUS CERAMICS (GGS)?
GORGEOUS CERAMICS (GGS) offers mass production, OEM/ODM support, custom design support, and a variety of custom sizes.
With 15 years of experience in ceramic manufacturing and ISO 9001:2015, IATF 16949:2016, and ISO 14001:2015 environmental management system certifications, we are able to provide customers with higher quality silicon nitride ceramic shafts.
SSS
What are the advantages of silicon nitride ceramic shafts?
High strength, lightweight, high wear resistance, and excellent thermal shock resistance are the main advantages of silicon nitride ceramic shafts.
Are silicon nitride shafts suitable for high-speed applications?
Yes, they are very suitable. Silicon nitride shafts have low density and high strength, making them ideal for high-speed rotating equipment, motors, and bearing systems.
Can silicon nitride shafts replace steel shafts?
In some high-performance applications, silicon nitride shafts offer longer lifespan, are lighter, and have better wear resistance than steel shafts.
Why are silicon nitride shafts used in turbocharger systems?
Their lightweight structure reduces rotational inertia, resulting in faster turbine response and higher efficiency.
