Zirkonyum Piston Parçaları
Zirconia Plunger Parts is a high-performance ceramic precision part, a ceramic plunger part designed for you to solve extreme environment applications. Ceramic plunger parts are essential parts in pumps, hydraulic equipment and various industrial machinery. Our plunger parts can bring you a more outstanding and perfect application experience!
The above products are just to show you that we can customize high-quality Zirconia Plunger Parts for you according to the drawings. Choose us and send us the drawings, and you will get higher equipment reliability and lower maintenance costs! The ceramic plungers we produce have more excellent wear resistance and longer service life, which can significantly reduce your costs and thus increase production efficiency! If you need ceramic plungers, please contact us today!
Characteristics of Zirconia Ceramics
Zirconia has excellent wear resistance and corrosion resistance, and performs better than metal plungers in some corrosive environments. At the same time, the strength and fracture toughness of zirconia plungers are very good. In addition, zirconia is non-toxic and can be used in medical equipment and food industries, which increases the scope of application of zirconia plungers.
|
Product name |
Zirkonyum |
|
|
density |
g/cm3 |
5.9-6.02 |
|
water absorption |
% |
0 |
|
thermal expansion coefficient |
10-6/k |
10.5 |
|
Rockwell hardness HRC |
MPa |
88-90 |
|
Bending strength |
MPa |
1200 |
|
Basınç dayanımı |
MPa |
2000 |
|
Kırılma tokluğu |
MPa.m1/2 |
10 |
|
Isı iletkenliği |
W/m.k |
2 |
|
Maksimum çalışma sıcaklığı |
℃ |
1350 |
Our processing accuracy
Our processing accuracy is for your reference and can meet the accuracy requirements of most ceramic plungers on the market. If you need high-quality ceramic plungers, please communicate with us and we will recommend the most suitable material selection and size for you.
|
Boyutsal doğruluk |
0,001 mm'ye kadar |
|
Sona ermek |
Ayna yüzeyine kadar |
|
Eşmerkezlilik |
0,003 mm'ye kadar |
|
Paralellik |
0,002 mm'ye kadar |
|
İç delik toleransı |
0,005 mm işlenebilir |
|
Düz yuva |
0,1×100mm'ye kadar oluk genişliğini işleyebilir |
|
Kalınlık |
0,3 mm'ye kadar işlenebilir |
|
İplik |
İç diş M2 işlenebilir, dış diş sınırlı değildir |
|
Silindiriklik |
0,004 mm'ye kadar |
|
Doğrusal tolerans |
0,001 mm'ye kadar |
|
Minimum açıklık |
İşlenebilir 0,5 mm (kalıp açıklığı 0,1 mm) |
Satış Sonrası Hizmetimiz
GORGEOUS attaches great importance to customers and strives to cooperate with customers for a long time. We will bring you the best after-sales service experience. If you have any questions after sales, our professional team will answer them one by one.
You don’t have to worry about the packaging of the plunger. We will carefully package your product to ensure that your product can reach you safely. At the same time, if it is damaged due to packaging problems, you don’t have to worry, we will compensate you!
If you need ceramic plungers urgently, please contact us immediately.
